PORTKEYS BM5 III 5.5" HDMI Touchscreen Monitor with Camera Control for RED KOMODO

0 reviews
Questions about this product?
  • 5.5" Wide Color Gamut Monitor
  • Ultrabright Touchscreen, Image Overlay
  • Focus Peaking, ARRI False Color
  • HDMI In, SDI In/Loop Out
  • SDI Output with New 3D LUTs
  • Histogram, Fullscreen Waveform
  • Low 13W Power Consumption

The PORTKEYS BM5 III 5.5" HDMI Touchscreen Monitor with Camera Control for RED KOMODO allows you to accurately capture seamless videos. The wireless control module offers Wi-Fi control for the RED KOMODO and Bluetooth control for BMPCC 6K/6K Pro and 4K cameras. Wired control is available for select Canon, Blackmagic Design, Panasonic, Sony, and ZCAM E2 cameras. The BM5WR with Camera Control maintains the same reliable BM5 clarity, vivid color details, and dynamic touch screen camera control, and it offers touch focus for the KOMODO, the Panasonic BGH1, and the ZCAM E2.

FEATURES:

  • 5.5" Wide Color Gamut Monitor
  • Ultrabright Touchscreen, Image Overlay
  • Focus Peaking, ARRI False Color
  • HDMI In, SDI In/Loop Out
  • SDI Output with New 3D LUTs
  • Histogram, Fullscreen Waveform
  • Low 13W Power Consumption
In the Box
  • PORTKEYS BM5WR 5.5" HDMI Touchscreen Monitor with Camera Control
  • 4-Pin Aviation to D-Tap Power Cord (39")
  • 4-Pin Aviation to DC Power Cord (16")
  • L-Type Antenna
  • LANC Control Cable (16")
  • USB Type-C Control Cable (16")
  • USB Flash Drive
Portkeys Logo
Portkeys
View Page
More Information
SKU116142
BrandsPortkeys
MPNBM5 III-WR
Product ConditonNew
Specifications
Display
Panel Type LCD
Display Size 5.5" / 14.0 cm
Resolution 1920 x 1080
Aspect Ratio 16:9
Viewing Angle Horizontal: 178°
Vertical: 178°
Touchscreen Yes
Maximum Brightness 2200 cd/m2 (Sustained)
Contrast Ratio 1000:1
Bit Depth / Color Support 10-Bit (1.07 Billion Colors)
HDR Compatibility Hybrid Log Gamma
Pixels Per Inch (ppi) 401 ppi
Real-Time LUT Monitoring SDR
Image Controls Anamorphic De-Squeeze, Check Field, False Color, Focus Peaking, Histogram, Image Flip, Image Rotate, RGB Parade, Screen Markers, Underscan, Waveform
I/O
Video 1 x BNC (3G-SDI/HD-SDI/SD-SDI) Input
1 x BNC (3G-SDI/HD-SDI/SD-SDI) Loop Output
1 x HDMI Type A Input
Embedded Audio SDI
HDMI
Audio None
Built-In Speaker None
Power I/O 1 x Unspecified 4-Pin (24 VDC) Input
1 x Unspecified 4-Pin (7.4 VDC) Output
Other I/O 1 x USB 2.0 (USB Type-A)
1 x USB 2.0 (USB Type-B)
1 x Proprietary
Media/Memory Card Slot None
Wi-Fi None
Format Support
Video Format HDMI (10-Bit)
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080PsF: 30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
576p: 50
576i: 50
480p: 60/59.94
480i: 60/59.94
SDI (10-Bit 4:4:4/4:2:2 RGB, YUV)
1080p: 60/59.94/50/30/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
Gamma Curve HDR-HLG
Power
DC Input Power 7.4 to 24 VDC
Power Consumption 13 W (Maximum)
Mounting
Mounting 1 x 1/4"-20 Female
General
Material of Construction Aluminum
Dimensions 5.7 x 4.8 x 1.8" / 145.4 x 120.9 x 45.5 mm
Weight 13.3 oz / 376 g
Packaging Info
Package Weight 1.475 lb
Box Dimensions (LxWxH) 7.7 x 4.7 x 3.3"
